ปั๊มหอยโข่ง MITSUBISHI รุ่น WCL ชนิดปริมาณน้ำมาก เหมาะสำหรับ งานเกษตรกรรม งานอุตสาหกรรม เป็นต้น มีทั้งแบบมาตรฐานและแบบหน้าแปลน มีทั้งหมด 5 รุ่น ได้แก่ WCL-1505S, WCL-1505T, WCL-2205FS, WCL-2205FT, WCL-3705FS, และรุ่น WCL-3705FT ระยะดูดลึกสุด 7 เมตร ความเร็วรอบสูงสุด 3,000 รอบต่อนาที
Centrifugal Pump MITSUBISHI WCL Series are centrifugal pumps. The amount of water Suitable for agriculture industrial sector and the desired quantity of water. Both standard and flange with all five models including WCL-755S, WCL-1105S, WCL-1505S, WCL-2205FS and WCL-3705FS Range 4 meters deep, maximum speed of 3000 rpm.
Centrifugal Pumps Mitsubishi WCL Series WCL-1505S, WCL-1505T, WCL-2205FS, WCL-2205FT, WCL-3705FS, WCL-3705FT
Large water pumps Suitable for agriculture industrial sector And various public utilities. Suitable for applications requiring large amounts of water. Both standard and flange. The Mitsubishi Motors, which is building the car’s performance. The pump is manufactured from cast iron And the pump shaft is made of stainless steel SS304. Brass Closed efficient in pumping high. The Mecklenburg seal with Nicholls sealing ceramic and graphite. The waterproof and last for long. Type squirrel cage induction motor off. Fan cooled IP55 protection standards used to identify the Class F insulation for use continuously. And the motor shaft into the pump shaft.
Model | HP | Max. Current (A) | FLOW | m3/Hr | 0 | 12 | 24 | 36 | 42 | 48 | 54 | 60 | 66 | 72 | ||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
10ø, 220V 50Hz | 3ø, 220V/380V 50Hz | 1Ø, 220V | 3Ø, 380V | RATE | l/min | 0 | 200 | 400 | 600 | 700 | 800 | 900 | 1000 | 1100 | 1200 | |
MITSUBISHI WCL-1505S | MITSUBISHI WCL-1505T | 2 | 14 | 5.3 | Total Head(m.) | 17 | 16.8 | 16.4 | 14.6 | 13.2 | 11.8 | 11 | 9.2 | 7.7 | – | |
MITSUBISHI WCL-2205FS | MITSUBISHI WCL-2205FT | 3 | 17.2 | 6.2 | 21.2 | 19.5 | 18.5 | 16.7 | 15.3 | 13.9 | 12.6 | 10.7 | 8.9 | – | ||
MITSUBISHI WCL-3705FS | MITSUBISHI WCL-3705FT | 5 | 24.8 | 8.9 | 26 | 26.1 | 24.8 | 23.4 | 22 | 20.3 | 18.1 | 15.7 | 13.1 | 10.2 |
