ปั๊มสุญญากาศ Edwards รุ่น nXDS Series เป็นปั๊มสุญญากาศแบบ Scroll Pump เหมาะสำหรับงานที่ต้องการความสะอาดสูง เพราะปราศจากน้ำมัน สามารถทำค่าแวคคั่มได้ในช่วง 0.02 mbar ไร้เสียงรบกวนเพราะระดับเสียงขณะทำงานเพียง 52 dB(A) เท่านั้น
Dry Scroll Pump EDWARDS nXDS Series It is a Scroll Pump air compressor suitable for applications that require high cleanliness, as it is oil-free. It can achieve a vacuum level of 0.02 mbar and operates quietly at only 52 dB(A).
ด้วยความสามารถในการปั๊มที่ยอดเยี่ยม ประสิทธิภาพสุญญากาศสูงสุดและการออกแบบที่ล้ำสมัย ทำให้ปั๊มลมสโครลแบบแห้งรุ่น nXDS มีประสิทธิภาพการทำงานที่ดีที่สุดในหมู่ปั๊มชนิดเดียวกันโดยปั๊มรุ่น nXDS ใช้แผงป้องกันตลับลูกปืนที่เป็นนวัตกรรมใหม่เพื่อแยกสุญญากาศออกจากสารหล่อลื่นทุกรูปแบบ ซึ่งไม่เพียงแต่ทำให้แห้งสนิทเท่านั้น แต่ยังช่วยปกป้องตลับลูกปืนจากแก๊สในกระบวนการต่าง ๆ ได้อีกด้วย
ปั๊มรุ่น nXDS ได้รับการปรับปรุงเทคโนโลยีจากปั๊มรุ่น XDS 5 และ 10 โดยมีการเพิ่มช่วงความเร็วของปั๊ม รวมกับแรงดันสูงสุดที่ค่าต่ำกว่า ทำให้ใช้พลังงานต่ำและลดเสียงรบกวน นอกจากนี้ ยังมีบัลลาสต์แก๊สที่ช่วยให้สูบไอระเหยควบแน่นได้ รวมถึงน้ำ ตัวทำละลาย กรดเจือจางและเบส ปั๊มรุ่น nXDS มีเทคโนโลยี tip seal รุ่นล่าสุด ทำให้มีอายุการใช้งานยาวนานขึ้นอย่างชัดเจนในระหว่างการเปลี่ยน tip seal
The nXDS dry scroll air pump is renowned for its exceptional pumping capabilities, high-efficiency performance, and cutting-edge design. Among pumps of the same type, the nXDS model delivers the best performance. It utilizes an innovative bearing shield technology to separate air from the lubricant in all forms, resulting in a completely dry and clean operation. Additionally, it protects the bearings from gases during various processes.
The nXDS pump has undergone technological advancements from the XDS 5 and 10 models, including an increased speed range and lower maximum pressure, resulting in reduced energy consumption and noise levels. It features gas ballast to handle condensable vapors, water, solvents, diluted acids, and bases.
Model | nXDS6i | nXDS10i | nXDS15i | nXDS20i | |
---|---|---|---|---|---|
Nominal rotational speed | 1800 rpm | ||||
Displacement | m³h¯¹ (ft³min¯¹) | 6.8(4.0) | 12.7 (7.5) | 17.1 (10.1) | 28.0 (16.5) |
Peak pumping speed | m³h¯¹ (ft³min¯¹) | 6.2 (3.6) | 11.4 (6.7) | 15.1 (8.9) | 22.0 (13.0) |
Ultimate vacuum (total pressure) | mbar(Torr) | 0.020 (0.015) | 0.007 (0.005) | 0.007 (0.005) | 0.030 (0.022) |
Minimum standby rotational speed | rpm | 1200 | |||
Speed control resolution (percentage of full rotation speed) | % | 1 | |||
Max inlet pressure for water vapour | mbar | 35 | 35 | 35 | 20 |
Max water vapour pumping rate | gh¯¹ | 110 | 145 | 240 | 220 |
Maximum continuous inlet pressure | mbar | 200 | 200 | 200 | 50 |
Voltage input | V | 100-127, 200-240 (+/-10%) | |||
Voltage frequency | Hz | 50/60 | |||
Motor power 1-ph* | W | 260 | 280 | 300 | 260 |
Power connector 1-ph | IEC EN60320 C13 | ||||
Recommended fuse | 10A, 250V a.c. rms | ||||
Weight | kg (lb) | 26.2 (58) | 25.8 (57) | 25.2 (56) | 25.6 (56) |
Inlet flange | NW25 | ||||
Exhaust flange | NW25 | ||||
Noise level** | dB(A) | 52 | |||
Vibration at inlet flange | mms¯¹ (rms) | < 4.5 | |||
Leak tightness (static) | mbar ls¯¹ | < 1×10¯⁶ | |||
Operating temperature range | °C (°F) | +5 to +40 (+41 to +104) |
